USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS Balance Board Protection With Bluetooth

USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
US STOCK
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth
USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS Balance Board Protection With Bluetooth

USA STOCK FAST UPS DELIVERY JBD 7S-20S 200A 21V 24V 48V 60V 72V Smart BMS  Balance Board Protection With Bluetooth

FAST UPS Shipping Continental United States ONLY, If you come from others or want ship by sea to save cost then please click here to send us inquiry(we will send you quotation via official email): Contact Info

JBD-AP20S003S is an intelligent protection board solution designed by Dongguan Jiabaida Electronic Technology Co., Ltd. for 7-20 battery packs of power batteries, electric bicycles, electric motorcycles and other products; it can be applied to lithium batteries with different chemical properties, such as lithium Ion, lithium polymer, lithium iron phosphate, etc. The protection board has strong loading capacity, and the maximum continuous discharge current can reach 200A.

Advantages:

1.Intelligent and powerful MOS, imported IC, integrated solution.

2.Equipped with temperature sensor, preserved control switch.

3.Factory sales, the more the quantity, the lower the price.

4.Support customization (the size of PCB / the material and length of balance wires and output line / the replacement of Aluminum shell material / change parameters / increase function of data storage ... )

5. Internal/2 External Temperature Sensors (Detect battery temperature)

Note: Support Series Connection

BMS Specification
Supportable Battery type3.7V Li-ion/3.2V Lifepo4
Voltage21V-72V
Current 200A
Phone Bluetooth App Xiaoxiang BMS APP
Computer applicationUART/RS485/CAN
Balance functionCommon port with balance
ProtectionOver-charge Protection Over-discharge Protection Over-current Protection Temperature Protection Short circuit Protection
Size165*114.5*76 MM
Ptional Heating Function2 Built-in, 1 extenal
1
$145.00
Ex Tax: $145.00
  • Stock: 38
  • Model: USJBD24V-70V200A
