USA Stock Presale JK B2A16S smart 2A active balancer from Jikong can add for Docan Solar LiFePO4 Battery pack and DIY box kits
US$50.00
US$50.00
Ex Tax: US$50.00
- Stock Qty: 10
- Model: JK 2A Active Balancer
This product has a minimum quantity of 16
Note:
This link is only for orders within the Continental United States.
You can easily track your order status on our website. We'll ship your order within 1-7 days after payment. It will be delivered to your door in 2-5 days via FedEx/UPS, with no tariffs.
Orders for USA stock pick-up can only be made offline. Please send inquiries directly and we'll respond within 24 hours
Payment Options: Goods and service fees (PayPal/CC/Visa, etc.) is 5%, Alternatively, bank transfer with a bank fee of approximately $48-$100 per payment
A single JK-B2A16S-TH equalizer is suitable for battery packs with 2-16 strings of cells in series. However, when the battery string voltage is lower than 20V, the equalizer needs to provide external 24V to 70V DC power. For the battery pack with 16 cells , the installation wiring method is shown in the following figure.
Device activation
Before powering on the power supply, check whether the balance cable is properly connected, whether the powersupply for the equalizer is within the required range, and whether the equalizer is properly placed before powering on theequalizer. Otherwise, serious consequences such as abnormal working or even burning may occur.
After confirming the preceding operations, power on the equalizer. The JK-B2A16S-TH equalizer does not have apower-on control switch. You only need to connect the power cable to the wiring terminal. Then the equalizer
automatically starts to work. The equalizer is designed to operate automatically and is powered on for the first time when the voltage of the first battery string of the battery pack is higher than 2.4V.
